200Ton Silicone Folding Cup Making Machine Stretch Blow Molding Machine ISO9001
Product Details:
Place of Origin: | Guangdong China |
Brand Name: | JUCHUAN |
Certification: | SGS CE ISO9001:2015 |
Model Number: | JC-VI-AO |
Payment & Shipping Terms:
Minimum Order Quantity: | 1set |
---|---|
Price: | USD 21800-40000one set |
Packaging Details: | Fixed with hard straps |
Delivery Time: | 45 days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100 Set/Sets per Month |
Detail Information |
|||
High Light: | 200Ton Stretch Blow Molding Machine,Stretch Blow Molding Machine ISO9001,200Ton Silicone Folding Cup Making Machine |
---|
Product Description
200Ton Silicone Folding Cup Making Machine Stretch Blow Molding Machine ISO9001
Detailed Product Description
Apply Grade: | Food Grade Silicone | Clamp Force: | 200Ton |
---|---|---|---|
Injection Method: | All In All Out | Machine Structure: | Vertical |
Total Power: | 30.3KW | Machine Dimensions: | 2600x2000x4000mm |
High Light: |
hydraulic power press machine,hydraulic oil press machine |
Silicone Folding Cup Making Machine Injection Stretch Blow Molding Machine Injection Molding Machine Price
Procedure of Making Silicone Baking Mats:
- Raw material preparation: raw materials such as raw rubber, transparent agent and accelerator are proportioned.
- rubber: After a certain temperature, the prepared raw rubber is kneaded to mix the rubber compound and the additive evenly, and the transparency of the produced product is consistent.
- the material: according to the size of the product, the size of the mold, the material is sliced.
- Vulcanization molding: The high-pressure vulcanizing machine is subjected to high-temperature vulcanization molding at 300 degrees to solidify the raw material of the rubber compound.
- Trimming: The semi-finished product molded by the vulcanizing machine has completed the hardness, specification and transparency of the product. The product pressed out from the mold will be accompanied by some useless side material, which needs to be manually trimmed and removed.
- surface treatment: because the surface of the rubber compound of the transparent rubber pad does not absorb glue, in order to be able to adhere to a variety of double-sided adhesive, the surface of the glue should be destroyed with a special treatment agent to destroy the surface structure of the adhesive surface, so that double-sided It is not easy to fall off after bonding, and the viscosity is firm.
Difference of Our Machine and Taiwan Machines:
- Taiwan machine with complicated structure, which mean it is difficult for maintaining & repairing; our machine with simple structure, easy for maintaining and repairing.
- Taiwan machine production speed is very slow, and much more energy consumption; our machine production can be 40% more faster than the Taiwan machines, and with less energy consumption;
- Our machine can do “all-in-all-out”, which is our own patent, and our machine can handle with the hard rubber as more that 85 degree hardness; Taiwan no “all-in-all-out”injection machine till the moment.
- We can offer free training at our factory when your staff come for trainning. Even we can offer free accomodation for your staff when training at our factory.
- Price: our price is somehow lower level than that in Taiwan.
Main Features of the Silicone Baking Mats Injection Molding Machine:
- Accurate and balanced oil path, barrel and plunger with special adjustment effect, good neutrality, low wear, not easy to leak glue, stable measurement, high precision, good balance and stability during injection
- It is more convenient than the traditional advanced first-in-first-out inspection. After the injection part is upgraded, there is enough operation space for maintenance.
- Prevent mold damage protection function (company patent)
- FIFO four-cylinder balanced injection structure
Main Technical Parameters:
Model | Unit | 200VI-AO | 300VI-AO | 400VI-AO | 600VI-AO | 800VI-AO | 1000VI-AO |
Clamping Force | Ton | 200 | 300 | 400 | 600 | 800 | 1000 |
Injection Capacity | cc | 2000 | 3000 | 4000 | 6000 | 8000 | 10000 |
Injection pressure | kgf/cm² | 1800 | 1800 | 1800 | 1800 | 1800 | 1800 |
Operation table size | mm | 550*560 | 700*700 | 700*700 | 850*850 | 1000*1000 | 1200*1200 |
Min. Mold Thickness | mm | 100 | 100 | 100 | 100 | 150 | 150 |
Plunger stroke | mm | 400 | 400 | 400 | 500 | 500 | 500 |
Distance of Thermo-plate | mm | 500~600 | 500~600 | 500~600 | 600~700 | 650~800 | 650~800 |
Distance of Tie bar | mm | 640*310 | 820*395 | 820*395 | 970*500 | 1140*600 | 1340*800 |
Die sinking type | 2RT-3RT-4RT-Upper Mold-Lower Mold | ||||||
Max. Operating Pressure |
Mpa | 20 | 20 | 20 | 20 | 20 | 20 |
Motor Power | hp | 15 | 15 | 15 | 20 | 20 | 25 |
Electric Heating Power | Kw | 15.3 | 24 | 24 | 29.75 | 35 | 42 |
Total Power | Kw | 30.3 | 39 | 39 | 48.75 | 54 | 64.5 |
Gross weight | Ton | 7.5 | 9 | 10 | 14.2 | 17.5 | 21 |
Dimension (L*W*H) |
mm | 2600*2000 *4000 |
2750*2265 *4200 |
2750*2265 *4200 |
3200*2500 *4350 |
L3450*W2750 *H4500 |
3750*3050 *5000 |
