200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine

Product Details:

Place of Origin: Guangdong China
Brand Name: JUCHUAN
Certification: ISO9001:2015
Model Number: JC- HI-FL

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: USD 21800-40000one set
Packaging Details: Fixed with hard straps
Delivery Time: 45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Set/Sets per Month
Get Best Price Contact Now

Detail Information

Clamp Force(Ton): 200 - 500 Injection Volume(cc): 2000 - 8000
Injection Pressure(kgf/cm2): 2000 Platen Size(mm): 550*560 - 900*900
Plunger Diameter(mm): 360 - 560 Min. Mold Thickness(mm): 100 - 200
Plunger Strok(mm): 400 - 500 Heating Plates Distance(mm): 500-600 / 600/ 700
Tie Bar Distance(mm): 640*310/ 820*395/ 1105*475 Mold Opening Type: 2RT-3RT-4RT-Upper Hanging Die-Lower Hanging Die
Max. Operating Pressure(MPa): 20 Motor Power(KW): 11
Heater Power(KW): 15.3 / 24 / 24.2 Total Power(KW): 26.3 / 35/ 35.2
Gross Weight(Ton): 7.8 / 9.5 / 10.5 / 28 Machine Distance L*W*H(mm): 3400*2400*2600 /3500*2600*2700 /3500*2600*2700 /5100*3400*3000
High Light:

Auto Parts Silicone Rubber Injection Molding Machine

,

High Accuracy Auto Parts Injection Molding Machine

,

Auto Parts Injection Molding Machine 200T

Product Description

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 0

Detailed Product Description
Plate Size: 550x650mm Clamp Force: 200Ton
Applications:: Automotive And Electronic Rubber Parts Structure: All-in-out Structure
Technoloyu: Complete Intellectual Property Rights Type: Vertical
High Light:

hydraulic power press machine

,

hydraulic oil press machine





Technological Innovation Energy Conservation:

  • The concept of green energy conservation has become more and more intensive in people's minds. Many plastic machine enterprises have made control and cost saving a top priority. At present, most plastic machinery have achieved energy-saving transformation. At present, the servo energy-saving technology has been successfully applied to the injection molding machine. Compared with the ordinary quantitative pump injection molding machine, the energy saving can be up to 80%. The energy consumption of the variable pump can be up to 50%. At the same time, the production efficiency is increased by more than 10%. The editor knows that the injection molding machine manufacturer It has begun mass production and will quickly become the mainstream product at home.
  • After research and development by researchers, electromagnetic heating (IH technology is a new high-frequency heating technology. Production of energy-saving and environmentally-friendly high-frequency heating system, heating efficiency increased to 90% up to 99.8% according to the installation and testing in various plastic processing enterprises, energy saving and environmental protection Frequency heating system is very obvious for plastic processing enterprises, saving electricity by 30%-70%. It fully reflects its energy-saving advantages, saving a lot of electricity cost for plastic processing enterprises, improving production efficiency and improving the environment of the workshop. Reduce indirect production costs.
  • Then convert the DC power into a high frequency and high voltage with a frequency of 20-40KHz. Electromagnetic heating equipment is specially made of high temperature resistant cable. Electromagnetic heating power saver is a device that uses electromagnetic induction principle to convert electric energy into electromagnetic energy for heating. The electromagnetic heating saver converts 220V50/60Hz AC to DC. The high-frequency and high-frequency current passing through the coil will generate a high-speed alternating magnetic field. When the magnetic field lines in the magnetic field pass through the magnetic conductive metal material, numerous small eddy currents will be generated in the metal body, so that the metal material itself can be heated at a high speed, thereby achieving an ideal. The heating effect.
  • It can also improve quality and improve working conditions. The servo injection molding machine not only saves resources and reduces costs. However, in the cost structure of injection molding products, electricity costs account for a considerable proportion. According to the requirements of the injection molding machine equipment process, the traditional injection molding machine oil pump motor consumes 80%-90% of the total equipment power consumption.



Rubber Machinery Development Trendency:

  1. The concept of rubber injection equipment was proposed in the mid-1940s; in the early 1970s, cold injection injection of rubber injection equipment began to be practically used in industry.
  2. Because the rubber injection equipment can realize high temperature and rapid vulcanization, the rubber injection equipment products are vulcanized in the sealed high pressure cavity after the preheating and plasticization before the rubber enters the cavity. The quality of the rubber injection equipment is uniform and stable, and the rubber injection equipment is accurate in size. The rubber injection equipment can realize fully automatic operation. Compared with the traditional molding method, the rubber injection equipment can increase the production efficiency by more than ten times. Therefore, the technology of producing the molded products by the cold injection injection machine of the rubber injection equipment has been widely used.
  3. Rubber Injection Equipment Injection Molding Machine is mainly used in the production of auto parts, industrial parts, electrical insulation parts, connector sockets, seals, cushions, shock absorbing covers, shoes, corks, vacuum hoses, jackets, valve cushions. , toys and fitness equipment. With the development of the automotive industry, the quality requirements for seals, electrical connectors, shock absorbers, etc. are getting higher and higher, and the demand for rubber injection equipment has increased by more than 12,000 times. The strong market demand for rubber injection equipment is rubber. The development of injection equipment provides an opportunity.
  4. At present, the main manufacturers of rubber injection equipment for rubber injection equipment are: rubber injection equipment REP company in France, rubber injection equipment Austria MAPLAN company, rubber injection equipment Germany WP company, rubber injection equipment STEINL company and rubber injection equipment DESMA, Rubber injection equipment Japan Matsuda Manufacturing Co., Ltd., rubber injection equipment Kobe Machinery Co., Ltd., rubber injection equipment Sanyou Co., Ltd., rubber injection equipment, Japan Steel Institute, rubber injection equipment, Italy RUTIL company.
  5. In the early 1970s, rubber injection equipment, rubber injection equipment, Beijing University of Chemical Technology and a factory in Shanghai, developed a successful XZL-200 screw pre-plastic one-line rubber injection equipment injection molding vulcanizer. China has introduced rubber injection equipment from Europe, the United States and Japan. On this basis, domestic manufacturers, such as Huatai, Huacheng and Huarong (now known as Qianpu), have begun to develop and produce rubber injection equipment.



Main Technical Parameters:

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 1





Application Products:

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 2





Packaging & Shipping

Shipping and packing

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 3

Company Information

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 4





200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 5



Our Main Products

1. Silicone rubber injection molding machine

2. Vertical hydraulic rubber injection machine

3. Horiontal silicone rubber injection machine

4. Liquid silicone injection molding machine

5. Vacuum compression machine

6. Silicone rubber hot press machine



200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 6



Exhibition Show:

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 7200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 8



Our Service

1. Free technology training: you can come for inspection and training for free.

2. Free Installation and debugging: Our engineers will teach you about the installation and debugging for free.

3. After-sales service: We will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage)

4. Online remote control for software problems, whatspp or wechat for video checking.

200Ton High Accuracy Auto Parts Silicone Rubber Injection Molding Machine 9
