China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine

China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine

Product Details:

Place of Origin: Guangdong, China
Brand Name: JuChuan
Certification: CE ISO9001
Model Number: JC-LV-1

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: $43,000.00 - $58,000.00/sets
Packaging Details: shrink film packing
Delivery Time: 45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000 Set/Sets per Month LSR machine
Get Best Price Contact Now

Detail Information

Condition: New Style: VERTICAL
Clamping Force: 100~300Ton Type: LSR Injection Molding Machine
Automatic: Yes After-sales Service Provided: Engineers Available To Service Machinery Overseas
Plastic Type: Other Injection Weight: 300~500cc
Injection Rate: 30g/s Opening Stroke: 300~350mm
Power: 11~20Kw Biggest Injection Rate: 180~210cc/s
Injection Pressure(kfg/cm2): 750 Kfg/cm2 Injection Volume(cc): 300~500
Screw Diameter(mm): 45,50,55 Motor Capacity(kw): 11~20
Gross Weight(Ton): 6.3~11 Model: JC-LV
Port: Guangzhou Clamp Force: 50-1000
Injection Volume: 500-4000 Platen Size: 300-700
Plunger Stroke: 300-500 Mold Opening Type: 2RT3RT4RT
Gross Weight: 5.5-10ton Injection Pressure: 1800
Opening Mold: 2RT3RT4RT
High Light:

silicone nipple production line 15hp

,

LIM System LSR Molding Equipment

,

LSR Molding Equipment 15hp

Product Description

China Factory Price LV series Silicone Laryngeal Mask LSR Injection Molding Machine







China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 0

LV Series Liquid Silicone Injection Molding Machine

Features:

  1. Reciprocal vertical Liquid Molding (LIM) system with Independent Intellectual Property Rights.
  2. Ingenious Injection cylinder mechanism for material loading/unloading, extending machine's working life and durability.
  3. Unique pneumatic injection shut-off/sealing nozzle mechanism.
  4. Highly accurate vertical dispensing system, achieving up to 0.15% accuracy.
  5. Three working stations with double plate design for improved efficiency.
  6. Suitable for electric insulator parts, various LSR containers, oil seals, automotive parts, and more.




Model 100LV-1 200LV-1 300LV-1
Clamping Force (Ton) 100 200 300
Max. Injection Rate (cc/s) 300 300 400
Injection Pressure (kgf/cm²) 1000 1000 1200
Injection Volume (cc) 2000 3000 5000
Platen Size (mm) 400*400 550*560 700*700
Plunger Diameter (mm) Φ250 Φ360 Φ450
Plunger Stroke (mm) 350 400 600
Min. Mold Thickness (mm) 51 110 110
Heating Plates Distance (mm) 300-400 500-600 600-700
Mold Opening Type 2RT-3RT-4RT Upper Hanging Die-Lower Hanging Die
Max. Operating Pressure (Mpa) 20 20 20
Heating Power (KW) 10 15.3 24
Gross Weight (Ton) 6 7.3 11
Machine Size L*W*H (mm) 2400*1650*3200 2600*2000*4000 2750*2265*4200



Product show

 China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 1

Application

China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 2China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 3

Related Products

China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 4



China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 5 China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 7

China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 9







Packaging & Shipping



Shipping and packing

 China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 11







Company information

* Guangzhou JuChuan Machinery Co. Ltd. has been established in 1997 with a covering area of 20,000 square meters and over 20 sets of processing equipment. Our major products are including silicone rubber injection molding machine, vacuum compression molding machine, hydraulic hot press machine, injection molds, customized equipment and auxiliary equipment like robot arms.

* Our products have gained the national patents with efforts of the esteemed engineers, the advanced R&D ability, and the long-term technical cooperation with German company. We have a completed quality management system and excellent after-sale service system based on the standard GB/T19001-2016/ISO9001-2015. With the idea of "Quality is the BASIC to create value", we commit to provide the best technical support and sales services for all our customers.

* Nowadays, our products export to Germany, Russia, Ukraine, Turkey, Thailand, Vietnam, Malaysia, Indonesia, India, Cambodia, Saudi Arabia, Sudan, South Africa, Nigeria, Kenya, Morocco, Pakistan, Iran, Tunisia, Egypt, Israel, Afghanistan, Kazakhstan, Guatemala and Mexico.





Our main products

Silicone rubber injection molding machine

Vertical hydraulic rubber injection machine

Horizontal silicone rubber injection machine

Liquid silicone injection molding machine

Vacuum compression machine

Silicone rubber hot press machine





China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 12



China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 13





Trade Show

China Factory Price LV series Silicone Laryngeal mask LSR Injection Molding Machine 14









Our service

1. Free technology training: you can come for inspection and training for free.



2. Free Installation and debugging: Our engineers will teach you about the installation and debugging for free.



3. After-sales service: We will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage)



4. Online remote control for software problems, whatspp or wechat for video checking.
