Vulcanizing Press Machine for Making Anti-vibration Rubber Shock Absorber Pad
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | JUCHUAN |
| Certification: | ISO9001:2015 |
| Model Number: | JC-HF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | $16000-$45,000.00/sets >=1 sets |
| Packaging Details: | Fixed in the container with hard straps. |
| Delivery Time: | 45 days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100 Set/Month |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Plate Vulcanizing Press |
|---|---|---|---|
| Voltage: | 380v | Dimension(L*W*H): | 2930*2350*2050mm |
| Weight: | 7.8ton | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Showroom Location: | None |
| Applicable Industries: | Manufacturing Plant | After-sales Service Provided: | Online Support, Video Technical Support, Engineers Available To Service Machinery Overseas |
| After Warranty Service: | Video Technical Support, Online Support | Local Service Location: | South Africa |
| Clamp Force(Ton): | 100~1200 | Plunger Stroke(mm): | 200~350 |
| Gross Weight(Ton): | 5~28.5 | Power(W): | 42kw |
| Port: | Guangzhou | ||
Product Description
Vulcanizing Press Machine for Making Anti-vibration Rubber Shock Absorber Pad
Machine Features:
1. Adaptable with different demolding methods like 2RT/3RT/4RT.
2. Accurate mold-in and mold-out position to ensure no damage to the molding.
3. Dual motor design for sale and independent working of the twin station.
Technical parameter:
|
Model |
Unit |
100HF |
160HF |
200HF |
250HF |
|
Clamping Force |
Ton |
100 |
160 |
200 |
250 |
|
Operation table size |
mm |
400*460 |
500*520 |
550*560 |
650*600 |
|
Plunger stroke |
mm |
200 |
250 |
250 |
250 |
|
Distance of |
mm |
200~300 |
250~350 |
250~350 |
250~350 |
|
Thermo-plate |
|||||
|
Distance of Tie bar |
mm |
490*230 |
590*270 |
640*310 |
745*310 |
|
Die sinking type |
Track-Suspension-2RT-3RT-4RT |
||||
|
Max Operating |
Mpa |
20 |
20 |
20 |
20 |
|
Pressure |
|||||
|
Motor Power |
hp |
7.5*2(5.5kw*2) |
10*2(7.5kw*2) |
10*2(7.5kw*2) |
10*2(7.5kw*2) |
|
Electric Heating |
Kw |
7.2*2 |
11.7*2 |
13.5*2 |
15.3*2 |
|
Power |
|||||
|
Total Power |
Kw |
25.4 |
38.4 |
42 |
45.6 |
|
Gross weight |
Ton |
5 |
6 |
7.8 |
11 |
|
Dimension(L*W*H) |
mm |
2500*2080*1950 |
2800*2260*1900 |
2930*2350*2050 |
3190*2780*2230 |
Machine detials
Related product:
|
|
|
Guangzhou Juchuan Machinery Co., Ltd. has been established in 1997 with a covering area of 20,000 square meters and over 20 sets of processing equipment. Our major products: silicone rubber injection molding machine, vacuum compression molding machine, hot press machine, injection moulds and the auxiliary equipment like robot arms.
Our products have gained the national patents with efforts of the esteemed engineers, the advanced R&D ability, and the long-term technical cooperation with German company. We have built up the complete quality management system and the after-sale service system, based on the standard of GB/T19001-2016/ISO9001-2015. With the idea of “Quality is the basic to create value”, we commit to provide the best technical support and sales services for all our clients.
So far, our products have been sold to Germany, Russia, Turkey, Thailand, Vietnam, Malaysia, Cambodia, India, Saudi Arabia, Sudan, Pakistan, Tunisia, Israel and Afghanistan.
Our Main Products
Vertical Solid Silicone Injection Molding machine
Vertical Rubber Injection Molding machine
Horizontal Silicone Injection Molding machine
Horizontal Rubber Injection Molding machine
Liquid Silicone Injection Molding machine
Vacuum compression Molding machine
Hydraulic Vulcanizing Hot Press machine
Brake Pads Brake Lining Hot Press Machine
Trade show
Our service:
1. Free technology training or machine inspection at our factory.
2. Free Installation and debugging: our engineers will teach you installation and debugging for free.
3. After-sales service: we will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage.)
4. Online remote control for software problems, Whatspp or Wechat for video checking.
