auto spare parts making machine, rubber bush making machine
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | juchuan |
| Certification: | sgs |
Payment & Shipping Terms:
| Price: | $16,800.00 - $36,800.00/sets |
|---|---|
| Packaging Details: | shrink film packing |
| Supply Ability: | 1000 Set/Sets per Month injection machine |
|
Detail Information |
|||
| Condition: | New | Machine Type: | Plate Vulcanizing Press |
|---|---|---|---|
| Voltage: | 380V | Dimension(L*W*H): | 2930*2350*2050 |
| Weight: | 7.8ton | Warranty: | 1 Year |
| Key Selling Points: | Famous Brand PLC | Showroom Location: | Egypt |
| Applicable Industries: | Manufacturing Plant | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Plate Size: | 550*560mm | Plunger Stroke: | 250mm |
| Daylight: | 250-350mm | Power(W): | 42KW |
| After Warranty Service: | Video Technical Support | Local Service Location: | Egypt |
| Port: | Guangzhou | Clamp Force: | 50-1000 |
| Plunger Stroke: | 200-350 | Mold Opening Type: | 2RT3RT4RT |
| Gross Weight: | 5-28.5 | ||
Product Description
rubber press molding machine for making rubber plug
Machine Characteristic:
- Able to assemble/install separate Ejection mechanism that suitable for bigger size molding part
- Efficient production of rubber part for railway, mining, shipbuilding industries
- Multi-pillar plate vulcanizing machine.
- Anti-collision Molding System prevents mold damage occurring from misalignment (Patented).
- It has various demolding method: 2RT, 3RT, 4RT.
- Accure mold positioning to ensure safety to that mold does not collide.
- Dual power bank design to ensure the twin stations could work independently and safely.
Technical parameter:
Model | Unit | 100HF | 160HF | 200HF | 250HF |
Clamping Force | Ton | 100 | 160 | 200 | 250 |
Operation table size | mm | 400*460 | 500*520 | 550*560 | 650*600 |
Plunger stroke | mm | 200 | 250 | 250 | 250 |
Distance of | mm | 200~300 | 250~350 | 250~350 | 250~350 |
Thermo-plate | |||||
Distance of Tie bar | mm | 490*230 | 590*270 | 640*310 | 745*310 |
Die sinking type | Track-Suspension-2RT-3RT-4RT | ||||
Max Operating | Mpa | 20 | 20 | 20 | 20 |
Pressure | |||||
Motor Power | hp | 7.5*2(5.5kw*2) | 10*2(7.5kw*2) | 10*2(7.5kw*2) | 10*2(7.5kw*2) |
Electric Heating | Kw | 7.2*2 | 11.7*2 | 13.5*2 | 15.3*2 |
Power | |||||
Total Power | Kw | 25.4 | 38.4 | 42 | 45.6 |
Gross weight | Ton | 5 | 6 | 7.8 | 11 |
Dimension(L*W*H) | mm | 2500*2080*1950 | 2800*2260*1900 | 2930*2350*2050 | 3190*2780*2230 |
Machine details
Related product:
| |
|
Shipping and packing
Company information
Guangzhou JuChuan Machinery Co.,Ltd was established in 1997. We are mainly specializing in producing silicone/rubber injection molding machines, Vacuum compression molding machines, plate vulcanizing machine, “all-in-out” ,liquid silicone injection machine, ”first in first out” ,”first in last out”, vertical and horizontal silicone/rubber injection machine for 20 years.
We have a special company patent: Anti-collision Molding System prevent mold damage occurring form misalignment.
Our service:
1. Free technology training: you can come for inspection and training for free.
2. Free Installation and debugging: Our engineers will teach you about the installation and debugging for free.
3. After-sales service: We will supply the free repairmen on this machine for one year, but will supply the maintenance lifetime. (The service is only for natural damage)
4. Online remote control for software problems, whatspp or wechat for video checking.
