Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force

Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force
Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force

Large Image :  Vertical AO 3000CC Upper Injection Moulding Machine For Silicone Rubber 300 Ton Clamping Force

Product Details:

Place of Origin: China
Brand Name: Juchuan
Certification: LFGB CE SGS
Model Number: JC-300VI-AO

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: shrink film packing
Delivery Time: 45 days
Supply Ability: 500sets per year
Contact Now
Detailed Product Description
Clamping Force: 300 Ton Injection Volume: 3000cc
Injection Pressure: 1800kgf/cm² Plate Size: 700*700mm
Min Mold Thickness: 100mm Plunger Stroke: 400(500)mm
Gross Weight: 9 Ton Machine Dimensions: 2750*2265*4200mm
High Light:

rubber injection moulding machine

,

rubber mould making machine

300 Ton Vertical Silicone Rubber AO 3000CC Upper Mold Injection Machine





Injection Machince Application:

Widely used in medicine, food, baby supplies, diving supplies, electrical insulation accessories and cable accessories and other liquid silicone products field.

  • Suitable for automotive and electronic rubber parts, high/cold temperature precision rubber parst, especially FPM/NBR/EPDM Products
  • All in all out structure, sprueless injection without material loss controlable injection material temperature.
  • Excellent for high precision molding parts.
  • 5-10 times better accuracy than conventional injection machine, the measuring precision of 1000cc injection volume is up to ±0.1g.
  • Anti-collision molding system prevent mold damage occurring from misalignment.
  • Servo-controlled system---up to 40% energy saving.
  • Proportional backpressure controlling characteristics.



Injection Feature:

  • Low speed and large torque hydraulic motor drives the screw directly, and the plasticization is strong and powerful
  • The glue system is used to measure the amount of the storage by the electronic ruler, and the measurement is accurate
  • Digital three or four level injection speed and pressure control.



Our specification list:

E-1.PLC Programmble Controller Japan Mitsubishi
E-2.Touch Screen (Human Machine Interface) Taiwan Panelmaster
E-3. Temperature .Controller Japan OMRON
E-4. Operation Switch Schneider
E-5. Magnetic Switch (Motor, Heater) Schneider
E-6. Touch Contactor/ Micro Circuit Breaker Japan Fuji
E-7 solid state relay(SSR) Taiwan Tian Hao






Machine Main Parameter:

Model Unit 200VI-AO 300VI-AO 400VI-AO 600VI-AO
Clamping Force Ton 200 300 400 600
injection volume cc 2000 3000 4000 6000
injection pressure kgf/c㎡ 1800 1800 1800 1800
Platen Size mm 550*560 700*700 700*700 850*850
Min Mold thickness mm 100 100 100 100
Plunger stroke mm 400(500) 400(500) 400(500) 500
Distance of Thermo-plate mm 500-600 500-600 500-600 600-700
Distance of Tie bar mm 640*310 820*395 820*39 970*500
Die sinking type 2RT-3RT-4RT-Track
Max Operating Pressure Mpa 20 20 20 20
Motor Power KW 11 11 11 15
Electric Heating Power KW 15.3 24 24 29.75
Total Capacity KW 30.3 39 39 48.75
Gross weight Ton 7.5 9 10 14.2
Dimension mm L2600*W2000*H4000 L2750*W2265*H4200 L2750*W2265*H4200 L3200*W2500*H4350
