Convenient Demolding Rubber Bladder Molding Machine With Four Column Tube Heating System

Convenient Demolding Rubber Bladder Molding Machine With Four Column Tube Heating System

Machine Brief Introduction:

the machine is mainly to used to vulcanize and mould the solid core tires.

it is controlled by plc controller,with frame structures, equpped with mould let out and in device, the tire mould can be opened by hydraulic cylinder, the finished tire is push out of mould by center cylinder, the device can up and down autoly according the working layer.

Tyre Molding Machine Main Features:

1. High-performance oil hydraulic system with automatic pressure compensation function can preset the time and pressure between two pressurizations and automatically conduct pressurization and depressurization supplemented with high-precision cylinder.

2. High-precision and abration-resistance guide pillar features strong loading force and stable lifting.

3. Imported KDB electric board features high-temperature resistance,abrasion resistance,fast thermal transmision and strength against deformation.

4. High-precison temperature sensor,together with LED temperature controller,built-in dense-point heating wire and tubular condenser,has the temperature range from normal temperature to 300°C.

5. Oil hydraulic system:the pressure range:30 ton,the maximum stroke of the cylinder:140mm.

Structure features:

• Dual-mold automatic hydraulic tire curing press ,the hydraulic system is driven by a hydraulic station one to five vulcanzing machine ,and can realize the process control function.
• The control system adopts PLC programmable controller as the real time control core ,the industrial computer as the main machine operation interface ,that can realize vulcanizing process parameter setting .
• The press is suitable for the production of electric motorcycle tires and bias tires with nitrogen gas or steam vulcanizing process.

Tyre Mould Injection Machine Advantages:

• First - in first - out molding structure, to avoid compound aging
• Low bed machine structure, easy for operating and demolding
• Apply to automotive tyre moulding, motorbike tyre moulding, electric-bike tyre moulding.
• Simplified technical process, can realize high temperature rapid vulcanization of rubber products and shorten production cycle.
• Products are accurate in size, uniform in physical and mechanical properties and high in quality, especially suitable for the molding and vulcanization of products.
• High qualified products, greatly reduce inferior products.
• Simple operation, reduced labor intensity, high degree of mechanization and automation

Main Technical Parameters:

Other Mode of This Machine:

Reference Images:
