Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory

Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory
Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory

Large Image :  Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory

Product Details:

Place of Origin: China
Brand Name: Juchuan
Certification: LFGB CE SGS
Model Number: JC-100VI-AO

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: shrink film packing
Delivery Time: 45 days
Supply Ability: 500sets per year
Detailed Product Description
Clamping Force: 1000KN Injection Volume: 500cc
Injection Pressure: 1800kgf/cm² Plate Size: 400*400mm
Min Mold Thickness: 50mm Plunger Stroke: 350mm
Heating Plates Distance: 400-500mm Machine Dimensions: 2400*1650*3200mm
High Light:

rubber injection moulding machine

,

rubber mould making machine

Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory





The vulcanization process is affected by several factors in the vulcanization process, mainly due to the following three factors.



1. Sulfur consumption

  • The higher the amount of sulfur in the vulcanizing machine, the faster the vulcanization rate will be, and the higher the vulcanization procedure will be. However, the solubility in sulfur and rubber is limited. It is not the greater the amount of sulfur used, the excess sulfur. It will be precipitated from the surface of the rubber compound. This phenomenon is called “sulphur spraying”. To minimize the occurrence of sulfur injection, the method is to add an appropriate amount of sulfur at the lowest possible temperature. Under normal circumstances, sulfur is used in soft rubber. Do not exceed 3%, semi-hard rubber does not exceed 20%, the amount of pure hard rubber is higher, up to 40%.

2. Vulcanization temperature



  • The vulcanization temperature determines the degree of vulcanization uniformity. When the temperature is 10 °C higher, the vulcanization time will be shortened by about half. The rubber is a poor thermal conductor, and the vulcanization process will be different depending on the temperature of each place. To achieve uniform vulcanization effect, thick rubber products The temperature control is very critical, and should be gradually warmed up. The principle is low temperature vulcanization for a long time.

3. Vulcanization time



  • Vulcanization time is an important link in the vulcanization process. If it is too short or the vulcanization process is not enough, it is commonly called “under-sulfur: if it is too long, the vulcanization degree will be too high, commonly known as “persulfurization”, only the appropriate length of time can be achieved. The best vulcanization effect, commonly known as positive vulcanization.



Main Brand Parts Used for Machine

E-1.PLC Programmble Controller Japan Mitsubishi
E-2.Touch Screen (Human Machine Interface) Taiwan Panelmaster
E-3. Temperature .Controller Japan OMRON
E-4. Operation Switch Schneider
E-5. Magnetic Switch (Motor, Heater) Schneider
E-6. Touch Contactor/ Micro Circuit Breaker Japan Fuji
E-7 solid state relay(SSR) Taiwan Tian Hao






Machine Main Parameter:

Model Unit 100VI-AO 200VI-AO 300VI-AO 400VI-AO
Clamping Force Ton 100 200 300 400
injection volume cc 500 2000 3000 4000
injection pressure kgf/c㎡ 1800 1800 1800 1800
Platen Size mm 400*400 550*560 700*700 700*700
Min Mold thickness mm 50 100 100 100
Plunger stroke mm 350 400(500) 400(500) 400(500)
Distance of Thermo-plate mm 400-500 500-600 500-600 500-600
Distance of Tie bar mm 515*230 640*310 820*395 820*39
Die sinking type 2RT-3RT-4RT-Track
Max Operating Pressure Mpa 20 20 20 20
Motor Power KW 10 11 11 11
Electric Heating Power KW 10 15.3 24 24
Total Capacity KW 20.5 30.3 39 39
Gross weight Ton 6 7.5 9 10
Dimension mm L2400*W1650*H3200 L2600*W2000*H4000 L2750*W2265*H4200 L2750*W2265*H4200





Reference Pictures:

Vertical 1000KN Plastify Visible 2 RT Oil Drilling Rubber Machinery For Factory 0
