Quality - Oriented, Offering Customer with Optimum Productivity and Profitability.
Product Details:
Payment & Shipping Terms:
|
| Clamp Force: | 500 Ton | Applications: | Composit Insulators; HTV Lightning Arrester |
|---|---|---|---|
| Injection Volume: | 10000CC | Injection Pressure: | 2000kgf/cm² |
| Platen Size: | 900*1100mm | Min Mold Thickness: | 200mm |
| Plunger Stroke: | 400mm | Heating Plates Distance: | 900mm |
| Tie Bar Distance: | 820*395mm | Mold Opening Stroke: | 2RT |
| Max Operating Pressure: | 20 MPa | Motor Power: | 22KW |
| Heater Capacity: | 45KW | Total Capacity: | 80KW |
| Gross Weight: | 20 Ton | Machine Dimensions: | L5200*W2600*H3500mm |
| High Light: | automatic rubber moulding machine,rubber transfer moulding machine |
||
500 Ton Silicone Lightening Arrester Injection Machine Horizontal HTV Injection Machine
why choose first in first out rubber injection molding machine
Adopting a first-in, first-out device to prevent dead material from remaining, and the rubber material can be easily replaced without waste.The temperature of the injection pipe oil is controlled by a constant temperature system to prevent vulcanization of dead glue.The use of low-speed high-torque hydraulic motors can ensure high hardness of the rubber material quickly.
Adopt linear vertical injection system to ensure the injection pressure and the hardness of injected rubber can reach 90 degrees.The device is equipped with a fully enclosed safety baffle and grating, alarm prompts and a high-precision measuring scale device, to clearly and safely grasp the status of the machine.Proportional oil circuit system, low noise and automatic pressure adjustment function, accurate and stable.Short nozzle designs, no spillage, no plastic leakage, can shorten the plasticization time.Special cold runner device can be customized to save rubber material.
Advantages between our machine and Taiwan Machine
Taiwan machine with complicated structure, which mean it is difficult for maintaining & repairing; our machine with simple structure, easy for maintaining and repairing.Taiwan machine production speed is very slow, and much more energy consumption; our machine production can be 40% more faster than the Taiwan machines, and with less energy consumption;Our machine can do "all-in-all-out", which is our own patent, and our machine can handle with the hard rubber as more that 85 degree hardness; Taiwan no "all-in-all-out"injection machine till the moment.
We can offer free training at our factory when your staff come for trainning. Even we can offer free accomodation for your staff when training at our factory.Price: our price is somehow lower level than that in Taiwan.
| Model | Unit | 300HI-FL | 400HI-FL | 550HI-FL | 600HI-FL | 800HI-FL | 1000HI-FL |
| Clamping Force | Ton | 300 | 400 | 550 | 600 | 800 | 1000 |
| Injection Capacity | cc | 3000 | 4000 | 10000(12000) | 6000 | 8000 | 10000 |
| Injection pressure | kgf/cm² | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
| Operate table size | mm | 700*700 | 700*700 | 700*1500 | 850*850 | 1000*1000 | 1200*1200 |
| Min. Mold Thickness | mm | 200 | 200 | 510 | 200 | 250 | 250 |
| Plunger stroke | mm | 400 | 400 | 700 | 500 | 500 | 500 |
| Distance of Thermo-plate | mm | 600 | 600 | 960 | 700 | 750 | 750 |
| Distance of Tie bar | mm | 820*395 | 820*395 | 820*640 | 970*500 | 1240*590 | 1340*800 |
| Die sinking type | 2RT-3RT-4RT-Upper ejector-Bottom ejector | ||||||
| Max. Operating Pressure |
Mpa | 20 | 20 | 20 | 20 | 20 | 20 |
| Motor Power | hp | 15(11kw) | 15(11kw) | 30/7.5 (22kw/5.5kw) |
20(15kw) | 20(15kw) | 25(18.5kw) |
| Heater Power | Kw | 24 | 24 | 45 | 29.75 | 35 | 42 |
| Total Power | Kw | 39 | 39 | 80 | 48.75 | 54 | 64.5 |
| Gross weight | Ton | 9.5 | 10.5 | 25 | 14.5 | 18.5 | 22 |
| Dimension(L*W*H) | mm | 3500*2600 *2700 |
3600*2600 *2700 |
5200*2600 *3500 |
3800*2800 *2800 |
4000*3050 *2900 |
4150*3250 *3200 |
Machine Reference Images:
If you want machine video and see how our machine produce silicone rubber products ,
please send enquiry to us!
